FC100 Trench Cutter
Features
The FC100 trench
cutter is a high-performance milling slotting machine product developed by the
design team of FUWA-XIAXING Technology based on years of experience in
designing and manufacturing continuous wall slotting machines, combined with
international advanced technology.
It has the characteristics of high operating efficiency, strong construction ability, low energy consumption, and flexibility. The hard layer wall forming equipment mainly used in the construction of underground space is the foundation construction of rail transit, transportation hub, civil construction foundation pit enclosure, water conservancy engineering, etc.
Technical data
|
Item
|
Unit
|
Data
|
| Engine power |
kW/rpm
|
641/1800
|
| Main winch lifting speed |
m/min
|
24~39
|
| Max. pull of main winch |
kN
|
350
|
| Main winch wire rope diameter |
mm
|
32
|
| Main winch wire rope length |
m
|
280
|
| Slew speed |
rpm
|
1.6
|
| Travel speed |
km/h
|
1.2
|
| Basic machine weight |
ton
|
117
|
| Counterweight weight |
ton
|
23
|
| Milling head height |
mm
|
13800
|
| Grooving depth |
m
|
85
|
| Grooving thickness |
mm
|
800~1500
|
| Max. torque of milling wheel |
kN*m
|
2×100
|
| Milling wheel speed |
rpm
|
25
|
| Mud pump flow |
m³/h
|
450
|
| Inside-diameter of mud pipe |
mm
|
152
|
FC120
Trench Cutter
Features
The FC120 trench cutter is a high-performance milling slotting machine product developed by the design team of FUWA-XIAXING Technology based on years of experience in designing and manufacturing continuous wall slotting machines, combined with international advanced technology.
It has the characteristics of high operating efficiency, strong construction ability, low energy consumption, and flexibility. The hard layer wall forming equipment mainly used in the construction of underground space is the foundation construction of rail transit, transportation hub, civil construction foundation pit enclosure, water conservancy engineering, etc.
Technical data
|
Item
|
Unit
|
Data
|
| Engine power |
kW/rpm
|
571/1800
|
| Main Hoisting Speed |
m/min
|
36
|
| Maximum Hoisting Force |
kN
|
390
|
| Diameter of MainHoisting Rope |
mm
|
36
|
| Length of Main HoistingRope |
m
|
280
|
| Rotation Speed |
rpm
|
2
|
| Traveling Speed |
km/h
|
1.1
|
| Weight of Main Machine |
ton
|
~138
|
| Counterweight weight |
ton
|
23
|
| Cutter Head Height |
mm
|
12500
|
| Trenching Depth |
m
|
150
|
| Trenching Width |
mm
|
800~1500
|
| Maximum Torque ofCutter Wheel |
kN*m
|
2×100
|
| Rotation Speed ofCutter Wheel |
rpm
|
25
|
| Flow Rate of SlurryPump |
m³/h
|
450
|
| Inner diameter of slurrynine |
mm
|
152
|
