Features:
1. Equipped with self-assembly/disassembly function;
2. Main components of power system and hydraulic system are imported from USA and Japan;
3. Hydraulic oil cooling system adopts single warm control to save energy;
4. Unique Free Fall on winches improve efficiency;
5. Luffing jib is as optional ;
6. Most parts of the crane adopts non-dust baked lacquer automatic assembling line painting;
Technical data
|
Item |
Unit |
Data |
||
| Max.rated lifting capacity |
t
|
150
|
||
| Boom length |
m
|
18.2～81.2
|
||
| Fixed jib length |
m
|
13～31
|
||
| Max. Length of Boom+ Fixed Jib |
m
|
69.2+31
|
||
| Max. Length of Boom+ Luffing Jib |
m
|
54.2+52
|
||
| Main Boom Angle |
︒ |
30-80
|
||
| Hook Blocks (Optional) |
t
|
150/100/50/15
|
||
| Working speed | Wire rope speed | Main winch hoist and lower(rope dia.Φ26mm) |
m/min
|
0～142
|
| Aux.winch hoist and lower (rope dia.Φ26mm) |
m/min
|
0～142
|
||
| Boom hoist and lower(rope dia.Φ22mm) |
m/min
|
0～30
|
||
| Swing speed |
r/min
|
0～2.3
|
||
| Traveling speed |
Km/h
|
0～1.25
|
||
| Reevings |
|
16
|
||
| Single line pull |
t
|
13.5
|
||
| Gradeability |
﹪ |
30
|
||
| Engine |
Kw/r/min
|
209/2000
|
||
| Swing radius |
mm
|
5845
|
||
| Transportation dimension |
mm
|
9750×3380×3580
|
||
| Crane mass(with basic boom, 150t hook) |
t
|
160
|
||
| Ground bearing pressure(including basic boom) |
Mpa
|
0.092
|
||
| Counterweight |
t
|
64
|
||
