Item |
Unit |
Data |
||
| Max.rated lifting capacity |
t
|
120
|
||
| Boom length |
m
|
16～73
|
||
| Fixed jib length |
m
|
13～25
|
||
| Max. Length of Boom+ Jib |
m
|
61+25
|
||
| Hook type |
t
|
120/50/9
|
||
| Working speed | Wire rope speed | Main winch hoist and lower(rope dia.Φ26mm) |
m/min
|
0～102
|
| Aux.winch hoist and lower(rope dia.Φ26mm) |
m/min
|
0～102
|
||
| Boom hoist and lower(rope dia.Φ20mm) |
m/min
|
0～54
|
||
| Swing speed |
r/min
|
0～1.96
|
||
| Traveling speed |
Km/h
|
0～1.3
|
||
| Reevings |
|
12
|
||
| Single line pull |
t
|
10
|
||
| Gradeability |
﹪ |
30
|
||
| Engine |
Kw/r/min
|
209/2000
|
||
| Swing radius |
mm
|
5227
|
||
| Transportation dimension |
mm
|
8850×3280×3030
|
||
| Crane mass(with basic boom, 120t hook) |
t
|
118
|
||
| Ground bearing pressure(including basic boom) |
Mpa
|
0.080
|
||
| Counterweight |
t
|
48
|
||
