Features
1. Multifunctional: can realize various applications such as lifting, percussion clamshell, mechanical grab, dynamic compaction, clamshell grab, etc;
2. More professional: adopting a stable wet clutch, controllable wet clutchfree fall winch,which can achieve load lowering and is more suitable forfoundationconstruction;
3. More reliable: The structural components are designed to resist fatigueandare more suitable for complex working conditions in foundationconstruction;
4.High efficiency: High power engine, fast lifting speed under heavy load, andcan achieve synchronous action of multiple winches.
Technical data
| Item | Unit | Data | |
| Main boom | Lifting capacity | t.m | 95×4 |
| Length of main boom | m | 13~58 | |
|
Main and auxiliary winch with wet-type free fall hook |
Max. Single line pull | kN | 250 |
| Diameter of wire rope | mm | 32 | |
| Max. lifting speed(1st layer) | m/min | 97 | |
| Length of wire rope | m | 175 | |
| Power system | Model | L9CS4-360 | |
| Rated power | kW | 264 | |
| Fuel tank | L | 450 | |
| Weight of counterweight | ton | 28+6.6 | |
| Ground pressure | kg/cm2 | 1.01 | |
|
Transport weight of whole machine (with crawlers, bottom boom) |
ton | 53.8 | |
|
Transport weight of whole machine (without crawlers, basic boom) |
ton | 36 | |
|
Weight of whole machine (with basic boom, central ballast) |
ton | 92.5 | |
